3 Dial 3 Way Concealed Thermostatic Overhead Shower With Handset And Bath Filler

All our valves have isolators and non-return valves meaning that they can be accessed from the front so, if a problem occurs it can be easily resolved without removing the valve from the wall. Most competitors’ valves do not have this feature.

Product Specifications

• Finish: Chrome plated to BS EN 248
• Shape: Square
• Minimum Pressure: 0.5 bar
• Maximum Pressure: 7.0 bar
• Inlet Connection Size: 3/4″
• Outlet Connection Size: 2 x 3/4″, 1 x 1/2″
• Additional Feature: WRAS Approved valve, Solid brass single cast body, non-return valve

3 Dial 3 Way Thermostatic Mixer Valve

• Top Dial – Controls water to 1 outlet diverter
• Middle Dial – Temperature Control
• Bottom Dial – Controls water to 2 outlet diverters
• High-Quality Design
• Chrome Finish
• Thermostatically controlled
• Manufactured from highly durable brass
• Operating range 20 – 50 deg C with 38 deg C safety button
• Built-in non-return valves to prevent backflow and filters to protect the thermostatic mechanism
• Chosen temperature maintained to within +/-1ºC
• Pre-set maximum temperature
• Automatic shut off in event of water cold supply failure
• UK standard size fitting

Shower Head

• Wall Mounted
• Easy clean anti-limescale rubber jets
• 200mm square shower head, with a high shine chrome finish
• Provides an even spray and full water coverage
• Swivel joint allows you to adjust the angle of the spray

Suitable Water Systems:

• Combination boiler systems
• Gravity fed systems (only with a pump)
• Megaflow system
• Pumped hot water systems
• Unvented hot water systems
• Standard pressurized hot water cylinder type systems

Package Includes:

• Concealed Thermostatic Valve
• Shower Head and Shower Arm
• Stainless Steel Shower Hose
• Rectangular Bath Filler Spout
• Wall Connector and Brackets
